Duct Hardware Self-Adhesive Pins Diameter 2.7mm
Short description:
Duct Hardware Self-Adhesive Pins Diameter 2.7mm
Long Descriptions
Self-adhesive pins
SAP
SAP-R
| Type | L (mm) | D (mm) | A (mm) |
| SAP-25 | 25 | 2.7 | 50 |
| SAP-33 | 33 | 2.7 | 50 |
| SAP-43 | 43 | 2.7 | 50 |
| SAP-53 | 53 | 2.7 | 50 |
| SAP-63 | 63 | 2.7 | 50 |
| SAP-76 | 76 | 2.7 | 50 |
| SAP-103 | 103 | 2.7 | 50 |
| SAP-115 | 115 | 2.7 | 50 |
|
Technical data
SAH self-adhesive nail
-steel pins,diameter 2.7mm
-self-adhesive,galvanized steel base(50/50mm)
-solid,synthetic resin rubber glue made of compact
cells filled with polyurethane foam
-length 19-165mm
-nail surface is knurled which prevents the blade
form sliding
-EC pressing blades
-galvanized steel elastic blades
-external diameter 30 or 40 mm.protective EP
nylon hood
-plastic hood protecting the nail tip
Use
Self-adhesive nails are used for mechanical fixing of insulation
materials on smooth surfaces of ventilation ducts.To be used within
temperature range from -40℃ to +80℃(for a short time up to 100℃)
|
SAPS
| type | L (mm) | d (mm) |
| SAZ-25 | 25 | 2.2 |
| SAZ-33 | 33 | 2.2 |
| SAZ-43 | 43 | 2.2 |
| SAZ-53 | 53 | 2.2 |
| SAZ-63 | 63 | 2.2 |
|
They are used to attach thermal insulation to a surface ventilation ducts.
It is equipped with metal PVC clip and cap.
|
SAPD
